Container mast M250-4, corner ballast MBNKON250-4
A mast designed for installation on a single shipping container in a corner configuration.
Goes well with
Only relationships confirmed in the descriptions and catalog.
Technical Specifications
Basic Information
- maximum wind load 1 m2 in the first wind zone
- weight of aluminum structure: ~22 kg,
- weight of steel structure: 3 kg,
- truss width: 250 mm
TECHNICAL DOCUMENTATION
Documents
- 1
- CAD
- in response to a request
- Access
- without a form
Description
A mast designed for installation on a single shipping container in a corner configuration. The base of the mast rests on a standard corner block, and the mast itself is held upright by two rigid braces. An excellent solution for temporary radio installations at construction sites, special events, or in locations where a permanent ground-mounted installation is not possible. Mounting the mast requires bolting (or welding) two mounting brackets to the container frame (lower strut mounts). If the container’s structure cannot be altered (due to rental agreements or warranty conditions), we recommend using the MBKON500 mast, which can be installed without interfering with the container frame.
Included in the set
- aluminum structure of the M250-4 mast
- screws
- two aluminum braces
- swinging base with a converter for the corner cube of the container (the details are adjusted to a specific model)
- lightning rod
