Steel lattice column with a base height of 6 meters in a configuration of 2 sections of 3 meters. Like each of our columns - the upper segment allows the replacement of the mounting plate with another available solution from the MG series. We can also develop an independent plate for your system - the possibility of adaptation is the strong point of our solution. The column is made of steel bars, thanks to the lattice structure it is particularly durable and stable in strong winds. The modular design (division into sections) facilitates any repairs in the event of damage (e.g. traffic damage) - only the lower segment can be replaced.
Technical parameters:
- Total height 6 meters
- Two 3 Meter sections
- Steel S235 Hot-dip galvanized
- Interchangeable sheets and top plates
- Adjustment on the floodlight bracket
- Top plate - not included in the price - please select the desired model and add it to the quote
- The weight of the entire truss with the plate is less than 96 kg
- Set of screws included
- Flanged connections 15 Mm sheet metal, fasteners – m20 Screws
Multimedia:
Product gallery:
Applications of the WSH6 Pole
The wSH6-W240-125 steel Lattice pole is designed for professional outdoor lighting applications where high mechanical strength and weather resistance are required. a Popular choice in Scandinavia and on polish industrial markets—the Open lattice structure reduces wind pressure while maintaining high structural rigidity.
- Parking Lots and Maneuvering Areas – precise illumination of large areas, even with a single pole equipped with a multi-arm head.
- Construction sites and temporary sites – The modular design and flanged connections make it easy to reconfigure the system once the project is complete.
- Industrial and logistics sites – The industrial look of the truss fits in well with the aesthetic of production facilities and warehouses.
- Residential Complexes and Commercial Properties – MG-2L/3L/4L light heads allow you to illuminate large areas with a single pole.
- Gas Stations and Car Washes – hot-dip galvanizing provides long-lasting resistance to chemically aggressive environments.
Why use a steel truss instead of a pipe?
A truss structure is the optimal choice wherever the weight-to-strength ratio and wind resistance are important:
- Higher torsional stiffness – Four support tubes connected by cross-braces form a structure that is more resistant to lateral deflection than a single tube of the same mass.
- Less wind pressure – The open truss structure significantly reduces the frontal area compared to a tubular column of the same height—a key factor in wind zones 2 and 3.
- Hot-dip galvanizing S235 / EN ISO 1461 – zinc coating applied by dip coating, with a minimum lifespan of 30 years without additional painting.
- Modularity and serviceability – The 3+3-meter section design simplifies transport and allows for the replacement of a damaged segment without having to disassemble the entire structure.
Compatible lighting heads (MG Series)
The WSH6-W240-125 pole is compatible with the interchangeable MG family of heads—you select them separately to match the number and type of LED fixtures:
- MG-1L / MG-2L / MG-3L / MG-4L – heads with swivel arms for 1–4 tubular lamps; fully adjustable lighting angle.
- MG-3LB – Rigid metal plate for 3 large industrial LED floodlights (spacing: W240 mm), high strength, central opening for cables.
- Custom board – Upon request, we design mounting solutions for custom lighting systems.
Frequently Asked Questions (FAQ)
Which LED floodlights are compatible with the WSH6-W240-125?
The pole is compatible with any LED fixture that has a tubular or sheet-metal mounting. 100–400 W floodlights are the most common choice for parking lots and industrial areas. The selection of the MG head depends on the number and weight of the fixtures.
How do you install the foundation for a WSH6 pole?
We recommend a concrete foundation or M20 chemical anchors set in drilled soil. The choice of foundation depends on the soil’s bearing capacity, the wind zone, and the load from the light fixtures—details are provided in the product data sheet available for download above.
Are the sections welded or bolted together?
The internal truss (bracing) is welded. The joints between sections (3+3 m) are flanged—using M20 bolts on 15 mm-thick plates—which allows for disassembly and reassembly without compromising strength parameters.
What is the turnaround time?
We manufacture WSH poles to order. The standard lead time is 3–6 weeks from the date the order is placed. Please contact us regarding larger orders or rush orders.
